STI's Series CNR950 is a compact canister style compression load cell

In The News...
Stellar Technology's Canister Load Cells -
Series CNR950

Stellar Technology introduces the Series CNR950 Load Cells. The Series CNR950 is a compact canister style compression load cell which incorporates an integral spherical load button for direct axial compressive loading from 2,000 lbf. to 2,000,000 lbf. These load cells are designed and manufactured for the most demanding application environments. Each load cell is constructed of welded stainless steel, utilizes hermetic connectors with glass-to-metal seals, and is manufactured with shock and vibration protection. Standard units operate in the temperature range of -65°F to +250°F. Besides the standard 2 mV/V output, many units (ranges of 50K lbf. and greater) are available with optional high level analog or digital outputs. Additional optional features include mounting threads, multiple bridges, extended operating temperature ranges, special calibrations, and metric configurations and ranges. Submersible configurations of the CNR950 are submersible to 30,000 ft. (9,150 meters) of seawater. Series CNR950 load cells combine 0.15% full scale linearity with durability, reliability, and very competitive pricing. . Each CNR950 load cell is shipped with a 5-point calibration record traceable to NIST.

Typical applications for Series CNR950 load cells include:
• Structural Testing
• Silo Weighing
• Railway Scales
• Truck Scales
• Tank Weighing
• Tension Link Indexing
• Storage Rack Weight Distribution
• Material Hoppers
• Weighbridges
• Barge Loading

...To learn more about this STI Application-Solution, click here.



Stellar Technology is a leading manufacturer of industrial transducers for
pressure, load, force, torque, displacement, and temperature measurement.


Since STI transducers are designed and manufactured in our state-of-the-art Amherst New York facility, we have the engineering resources and manufacturing flexibility to customize any transducer to accommodate the ever-changing test and measurement challenges faced by today's demanding industrial environment.

STI offers a sizable selection of stocked pressure sensors and stocked load cells as well as modified standard and customized pressure sensors, load cells, temperature sensors and torque transducers to give you countless variations to meet whatever application challenges you encounter.

Our willingness to create one-of-a-kind transducers for unique applications sets us apart from the competition, and insures that we can solve your application challenges.

STI strives to be the leader in transducer technology, from submersible load cells and pressure transducers performing on offshore oil rigs to pressure and temperature transducers used on the Mars Science Lab, to critical measurements on the space shuttle, to supply and cargo spacecraft servicing the International Space Station.
